Name: Energy Saving Homemade Liquid PSA Nitrogen Generator ISO9001 2008
Brand: SINCE GAS
SKU: PN-20-59
Rating: 5 (192 reviews)

Rumah Produk PSA Nitrogen Generator

Energy Saving Homemade Liquid PSA Nitrogen Generator ISO9001 2008

Detail produk:

Tempat asal:	Suzhou
Nama merek:	SINCE GAS
Sertifikasi:	CE,,ABS,DNV,TS,BV etc
Nomor model:	PN-20-59

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Negotiable
Kemasan rincian:	Standard exporting package
Waktu pengiriman:	within 60 days
Syarat-syarat pembayaran:	L/C, T/T, Western Union, MoneyGram
Menyediakan kemampuan:	80 sets per month

Kontak

Detil Deskripsi produk

Bahan:	Baja karbon atau baja tahan karat	Kemurnian:	99,999%
Spesifikasi:	Buatan sendiri	Tekanan:	7 batang
Titik embun:	-65 ℃	Karakteristikc:	Portabel, dapat dipindahkan
Cahaya Tinggi:	sa pabrik nitrogen , sistem pembangkitan nitrogen psa , Generator Nitrogen PSA ISO9001

Hot sale Verified high purity homemade liquid nitrogen generator

Description:

1.1) High purity
1.2) Excellent energy-saving
1.3) Smoothly running,long-life
1.4) Automatic operating
1.5) Certificate:ISO9001:2008

NO	Item	Notes
1	Nitrogen	High purity 99.9995%
2	Energy	Excellent energy-saving
3	Working life	＞20 years
4	Operating method	Fully automatic
5	Certificates	CE,TUV,,CCS approved

The Nitrogen Generator uses two twowers of CMS to separate nitrogen from the compressed air, remove other gas like oxygen, CO2 etc , Typical feed air pressure is 110 psig/7.6 barg. Typical nitrogen product purity for SINCE GAS systems is 99.998%. Product flow rate for the same system will be higher with better nitrogen recovery if a higher oxygen content can be accepted in the nitrogen product. Systems are available with a product purity up to 99.999% nitrogen. Presently, our nitrogen generator purity range from 95%-99.9995%, flow 5Nm3/hr -5000 Nm3/hr

Technical features :

Principle: passage of compressed air through a bed of carbon molecular sieve (CMS) using presure swing adsorption technology, the most reliable on the market
N2 flow: 5-5000 Nm3/h
O2 purity: 1% to 10 ppm
On-line monitoring instrument
Digital hours counter Audible and visual maintenance indicator
Economy mode option: via pressure to enables the compressor shut & start-up when nitrogen supply is not required

Specifications :

No	Model	Nm3/h	Purity	Power(KW)	Overall size(mm)
1 2 3 4	PN-3-39 PN-5-29 PN-5-295 PN-8-295	3 5 5 8	99.9% 99.5% 99% 95%	0.5	180014001500
5 6 7 8	PN-5-49 PN-8-39 PN-12-295 PN-15-29	5 8 12 15	99.99% 99.9% 99.5% 99%	0.5	180014001800
9 10 11 12	PN-10-49 PN-15-39 PN-25-295 PN-30-39	10 15 25 30	99.99% 99.9% 99.5% 99%	0.5	200017002250
13 14 15 16	PN-15-49 PN-22-39 PN-35-295 PN-45-29	15 22 35 45	99.99% 99.9% 99.5% 99%	0.5	210018002200
17 18 19 20	PN-20-49 PN-30-39 PN-50-295 PN-60-29	20 30 50 60	99.99% 99.9% 99.5% 99%	0.5	220018002200
21 22 23 24	PN-30-49 PN-45-39 PN-75-295 PN-88-29	30 45 75 88	99.99% 99.9% 99.5% 99%	0.5	240019002200
25 26 27 28	PN-40-49 PN-60-39 PN-100-295 PN-120-29	40 60 100 120	99.99% 99.9% 99.5% 99%	0.5	250021002500
29 30 31 32	PN-50-49 PN-70-39 PN-120-295 PN-140-29	50 70 120 140	99.99% 99.9% 99.5% 99%	0.5	260022002850
33 34 35 36	PN-60-49 PN-90-39 PN-160-295 PN-190-29	60 90 160 190	99.99% 99.9% 99.5% 99%	0.5	280022002500
37	PN-80-49	80	99.99%	0.5
38 39 40	PN-120-39 PN-200-295 PN-250-29	120 200 250	99.9% 99.5% 99%	0.5	320014002800
41 42 43 44	PN-100-49 PN-140-39 PN-250-295 PN-290-29	100 140 250 290	99.99% 99.9% 99.5% 99%	0.5	350015002800
...	...	...	...	...	...
Note:More news please free to contact Since Gas System Co.,Ltd or send email to us directly

Why SINCE-GAS?
-COST SAVINGS
You can save Nitrogen costs by generating your our nitrogen on-site, produce your own nitrogen , payback only couple of months .
Save on:
Transporation Costs
Bulk Liquid Evaporation Loss
Renting costs
Handling and Purchasing Costs
- Convenient
Produce your own nitrogen for production line , demand, to avoid transporation fault cause stop production line problems.
