Name: 90-95% Purity VSA Oxygen Generator 100-5000m3/h Flow
Brand: JoShining Energy & Technology Co.,Ltd
SKU: VPSA-1200-12B
Price: 700,001.00 USD
Availability: InStock

Rumah > Produk > GENERATOR OKSIGEN VSA >

90-95% Purity VSA Oxygen Generator 100-5000m3/h Flow

100-5000m3/h VSA Oxygen Generator

Purity 95% VSA Oxygen Generator

Purity 90% VSA Oxygen Generator

Tempat asal:

Suzhou, Cina

Nama merek:

Since

Sertifikasi:

Nomor model:

VPSA-1200-12B

Hubungi kami

Permintaan Penawaran

Detail Produk

Bentuk proses:

Adsorpsi ayunan tekanan vakum （VPSA）

Kemurnian:

90 - 95%

Mengalir:

100m3 - 5000m3 / jam

Tekanan outlet:

20Kpa - 0,5Mpa

Unit konsumsi produksi oksigen:

0,36kmj - 0,40kmj/NM3

Area tertutup:

500m2

Kehidupan:

15 tahun +

Menyoroti:

100-5000m3/h VSA Oxygen Generator

Purity 95% VSA Oxygen Generator

Purity 90% VSA Oxygen Generator

Syarat Pembayaran & Pengiriman

Kuantitas min Order

1set

Harga

according to customer needed equipment

Kemasan rincian

Kasing kayu

Waktu pengiriman

5 bulan

Syarat-syarat pembayaran

L/c, t/t

Menyediakan kemampuan

300set per tahun

Produk terkait

Video

VSA Oxygen Generator / VSA Oxygen Plant For Medical 93% Purity

Dapatkan Harga Terbaik

Video

High Efficient VSA Oxygen Generator / VSA Oxygen Plant For Ozone Generation

Dapatkan Harga Terbaik

Video

Cost Saving VSA Oxygen Generator / VSA Oxygen Plant For Pulp Paper Bleaching

Dapatkan Harga Terbaik

Hubungi kami

Hubungi Sekarang

Deskripsi produk

Fully Automatic VSA Oxygen Generator/Plant for Gold Mines

Our fully automatic VSA Oxygen Generator provides a cost-effective solution for gold mining operations, delivering stable oxygen-rich gas (90-95% purity) for cyanide-based gold extraction processes.

Why Gold Mines Need VSA Oxygen Generators

VPSA/VSA oxygen generators transform oxygen from an expensive purchased material into an inexpensive, self-produced process gas, revolutionizing gold extraction economics.

Key Benefits for Gold Mining Operations

Economic: Dramatically reduces oxygen costs, lowering per-ounce production expenses
Efficient: Improves leaching rates and equipment capacity, effectively increasing production
Environmental: Reduces cyanide usage, easing environmental treatment requirements
Reliable: Independent oxygen production ensures stable supply unaffected by market fluctuations

Technical Specifications

Oxygen Parameters
Flow Nm³/h	1200～1300	93% Total oxygen flow at purity
Pressure PSI	11～13	With full oxygen combustion system
Purity %	93%
Altitude	1280
Public and Auxiliary Engineering Requirements
Power consumption KW	576 +/-5%	Design conditions under full load flow
Cooling water recycle system T/h	N/A
Instrument air Nm³/h	~ 120
Seal water softening m³/h	N/A	Dry vacuum fan unique technology
Area m²	350 ~ 500	Adjustable according to actual requirements
Other Performance Parameters
Lead Time (months)	5
Load regulation %	50~100	Variable power saving
Noise dBA	<=85	Based on typical plant design conditions
Annual opening rate %	>=98%	Annual maintenance stops less than 7 days
Gas supply reliability %	100%	With liquid oxygen backup system
Liquid Oxygen Standby (Optional)
Liquid oxygen backup system m³	50	On-site system (sufficient for 40+ hours usage)

Process Flow

Air inlet filter → Air blower (in container) → Adsorber A → Adsorber B → Gox buffer → Compressor (in container) → Oxygen storage tank → outlet _l l _ Vacuum pump (in container)

Global Applications

We have successfully supplied VSA Oxygen Generators to gold mining operations in Philippines, Russia, Myanmar, Indonesia, Ghana, Algeria, and other countries worldwide.
