Fully Automatic High Purity 99.9995% Hydrogen Dryer Equipment for Chemical

Detail produk:

Tempat asal:	Suzhou,China
Nama merek:	SINCE-GAS
Sertifikasi:	CE,ABS,CCS,BV,DNV,ASME,GOST,
Nomor model:	PH-A-H

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	Negotiate
Kemasan rincian:	Normal exported wooden case
Waktu pengiriman:	2 months after received down payment
Syarat-syarat pembayaran:	L/C, T/T, Western Union, MoneyGram
Menyediakan kemampuan:	1000 sets/year

Kontak

Detil Deskripsi produk

Bahan:	Baja karbon/Baja tahan karat	Kapasitas:	50-5000Nm3/jam
Titik embun:	-70 ℃	Negara:	Barang baru
Metode operasi:	Sepenuhnya otomatis	Aplikasi:	Pengering pengering hidrogen untuk Bahan Kimia
Cahaya Tinggi:	Pengering Udara Desiccant , Pengering Udara Terkompresi Pendingin , Peralatan Pengering Hidrogen Kemurnian Tinggi

Fully Automatic High Purity 99.9995% Hydrogen Dryer Equipment for Chemical

Hydrogen dryers

Hydrogen dryer for hydrogen-cooled generators is a dual-absorber unit that continuously removes moisture from recirculated hydrogen, keeping the internal components of the turbine in a completely

dry hydrogen atmosphere. The unit uses regenerative type desiccant and is fully automatic

in operation. It is heat reactivated with embedded electric heaters.

Accomplishes reactivation with a completely closed-circuit system, thereby eliminating any purge loss

or infiltration of atmosphere into the system.

High quality desiccants

High quality, extra activated alumina is respectively filled in each tower ;

Controller Reliable Timed controller Field proven over time, this design and technology maintain precise

control over all switching and purge valve functions.

Opional for PLC controller,PLC Controlling system

executes and monitors all dryer functions;

7 Colorful Touch screen panel displays dryer status.

Pressure Gauges Stainless steel gauges, located on each tower, provide visual indication of
